Testomat 808 SILICA
Online Analyzer for Limit Value Detection
Key features:
- Measuring chamber flushed with pressure FOR SILICA UP TO 1.2 PPM
- Low water consumption
- Cutting-edge electronics
- State-of-the-art indicator pump system
- Direct error and indicator quantity display
- Quality management with 2 relay outputs
- Limit value evaluation / External control
- Alarm processing
- Internal flushing via manual control
- 72 hours of unsupervised operation possible
- Selection between two indicator bottle sizes
- Two selector switches for interval measurement
and limit value evaluation
The Testomat® 808 SiO2 has been designed for use in the sterilization of equipment in hospitals, in compliance with the EN 285:2006 standard. The device serves as a limit gauge, automatically monitoring the level of SiO2 in the water, providing a choice between 10 limits in the range of 0.3 to 1.2 ppm.
Range of Application
- Sterilization of equipment in hospitals
- Silica monitoring
Measuring Range
Silica SiO2: 0.3 – 1.2 ppm
Technical Data
| Measuring method | Titration |
| Self-calibrating | Yes |
| Power supply | 24 VAC OR 120 VAC OR 240 VAC |
| Power consumption | Max. 50 W |
| Output signal | 4-20 mA and dry signal |
| Degree of protection | IP 44 |
| Ambient temperature | 50 – 104°F (10 – 40°C) |
| Dimensions (W x H x D) | 11 x 14 x 6 inch |
| Weight | 18 lbs |
| Country of origin | Germany |
Water Supply
| Operating pressure | 4.4 to 15.4 psi (0.3 to 1 bar) OR 14.5 to 116 psi (1 to 8 bar) |
| Min. water flow | 14 fl oz (400ml) per minute |
| Water inlet | 1/4-inch quick connect fitting |
| Drain | 1/2 tube |
| Water temperature | 50 – 104°F (10 – 40°C) a cooler can be installed for temperatures above 104°F |
| Reagent | Total silicate | Quantity in ml | Order number | Safety data sheet |
| Reagent set (A + B) | 0.3 – 1.2 ppm | 100 | ||
| Reagent B | 0.3 – 1.2 ppm | 500 | 141809 |  |
| Reagent A | 0.3 – 1.2 ppm | 500 | 141808 | |
